Semi-automatic Aluminum Foil Rewinding Machine

  • Semi-automatic Aluminum Foil Rewinding Machine
  • Semi-automatic Aluminum Foil Rewinding Machine
  • Semi-automatic Aluminum Foil Rewinding Machine

Applicaton
Semi-automatic aluminum foil rewinding machine is used to rewind the aluminum foil for food container and can make it from jumbo roll into multiple finished products of rolls with same width.

This rewinding machine is semi-automatic, but it can be operated easily. The aluminum foil can be rewinded by the exclusive air shaft. In addition, this rewinding machine mainly reminds long aluminum foil and the finished product is smooth and can't be wrinkled.

Parameters
Model HTR-F600
Width of mother roll Max600mm
Width of finished roll Max600mm
Speed Max500m
Mother roll diameter 600mm
Finished roll diameter Max100mm
Core of mother roll 3"
Core of finished roll Customized
Dimension 1700*1350*1000/mm
Net weight 500KG

Features
1. This rewinding machine has control system consisting of PLC, human-computer interface and frequency changer. So this machine has high level of automation.
2. The finished product is very smooth under the control of air shaft and magnetic powder brake.

Wintech has researched and developed the slitter rewinder about 20 years and we have very professional technical team. Our technical staffs all have rich operational experience and can deal with different situations. All types of machine have one year free warranty and except for some particular equipment, we provide the fittings freely to replace the broken ones. In addition, our engineer can go to your workplace if necessary. In order to eliminate both sides' trouble, our machines are all examined more than three times by the professional engineer before sales.
